Name: Samlex 12v 100 Watt Solar Panel Kit SSP-100-KIT
Brand: Samlex
SKU: SSP-100-KIT
Price: 314.95 USD
Availability: InStock

Overview

The Samlex 12v 100 Watt Solar Panel Kit includes a high efficiency 100 Watt solar panel, mounting brackets with hardware, and connecting wires. The SSP-100-KIT offers a low-profile panel design with high efficiency crystalline solar cells.

Samlex America panels are weather resistant and built to last - even in harsh conditions of hail or heavy snow. Aluminum frames will not rust. 14-17.5% efficiency, 2x more than amorphous silicon panels! Samlex guarantees its solar panels with a 25 year power warranty.

Every Kit includes a set of aluminum mounting brackets and hardware for mounting the solar panel to a RV rooftop. To ensure a leak-free installation, Samlex provides industry leading Well Nuts that expand to prevent moisture from getting inside your RV.

The SSP-100-KIT comes with UV protective connecting wires to combat weather decay. Many other manufacturers use inexpensive cables and connectors without weather protection which can errode after a few years of use. Samlex cables are built to perform consistently in the toughest conditions, and Samlex does not believe in cutting corners when it comes to quality!

Unit comes with:

Samlex 100 Watt Solar Panel
Mounting brackets with hardware (leak free fasteners)
Pair of 20' Solar Connecting Wires

*Shipping does not include fees for highly rural location, hard to reach locations, islands or location requiring ferry's. These locations may be subject to additional shipping fees. You will be advised prior to your order being processed if additional fees are required, at which point you may proceed with the order if accepted.

Features

High efficiency crystalline solar cells
20 to 31 amps a day output (dependent on light conditions)
Low profile panel design
All weather Anodized aluminum and Tempered Glass construction
25 year Power Warranty
Top quality cable & mounting hardware

This Product Replaces These Other Products

Works In

Vehicles that SSP-100-KIT works in

Technical Specifications

Dimensions (LxWxH): 21.73 x 47.25 x 1.39 in
Weight: 26.4 lb
Shipping Weight: 33 lb
Nominal Maximum Power At STC, Pmax: 100w ± 3%
Maximum Power Voltage, Vmp: 19.29 V
Maximum Power Current, IMP: 5.18 A
Open Circuit Voltage, Voc: 22.93 V
Short Circuit Current, Isc: 5.81 A
Module Efficiency: 15.10 %
Type of Cells: Monocrystalline; 125 x 125mm / 4.92 x 4.92”
No. of Cells: 36
Maximum System Voltage: UL-1703: 600VDC; IEC-61215 / 61730: 1000VDC

Series Fuse Rating: 10A
Terminal Box: IP-65 with 2 Bypass Diodes; Cable 4mm2 with MC4 Compatible Connectors
Operating Temperature: − 40°C to + 85°C / − 40°F to +185°F
STC: Irradiance Level: 1000 W/M2
Temperature Coefficient of Current, Isc: +0.04% / °C
Temperature Coefficient of Voltage, Voc: −0.33% / °C
Temperature Coefficient of Power, Pmax: −0.37% / °C
UPC: 622988180408
Made in: Asia
Manufacturer: Samlex
Manufacturer’s Part Number: SSP-100-KIT
Model: SSP-100-KIT
